Godrej FHP Motors

Godrej FHP Motors Specification

Rated Voltage
230/415 V

Cooling Method
TEFC

Torque
High starting torque

Power Rating
0.25 - 3 HP

Motor Type
FHP (Fractional Horse Power) Induction Motor

Sealed Type
Totally Enclosed Fan Cooled

Horse Power
0.25 - 3 HP

Efficacy
High efficiency

Noise Level
Low

Rated Frequency
50 Hz

Features
Compact size, High efficiency, Robust construction

Standard
IS:996, IS:325

Bearing Type
Double sealed ball bearing

Current Type
AC

Starting Type
Direct On Line

Voltage
230/415 V

Poles Number
2/4

Ambient Temperature
-15C to +40C

Product Type
FHP Motor

Output Power
0.18 - 2.2 kW

Frequency (MHz)
50

Protect Feature
IP55

Phase
Single/Three Phase

Speed
1440/2880 rpm

Power
0.25 - 3 HP

Color
Grey

Dimension (L*W*H)
Depends on model

Weight
Approx. 8-28 kg

Shaft Diameter
14 mm (typical)

Mounting Type
Foot/Flange

IP Rating
IP55

Material
High-grade cast iron / aluminium

Applications
Machinery, Pumps, Compressors, Textile, Packaging

Vibration Level
IS standard compliant

Insulation Class
Class B/F

Duty Cycle
S1 continuous

Sound Level
<70 dB

Thermal Protection
Available on request

Rotor Type
Aluminium die-cast

Service Factor
1.0

Finish
Powder coated

Connection
Terminal box / Flying leads

Frame Size
56 to 90S

Humidity Tolerance
Up to 90% RH

Godrej FHP Motors Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
1 Week

About Godrej FHP Motors

Range : Motor Solutions has a wide range of motors ranging from 0.25 kW to 3 kW (1/4 HP to 4 HP) in single phase.
Types of Mountings : Foot, Stator Pad, Flange, Foot Cum Flange, Endshield Pad & Stud.
Standards : Frames B42, B48 & B56 conform to BS 2048 part 1 for dimensions and BS 5000 part II / IS996 for performance.
100s frame motors : Conforms to IS 996 for dimensions and BS 5000 part 11 / IS 996 for performance.
Electronic switch.
Circuit breaker.
Thermal protector Manual or Auto Reset.
MCB switch.
UL/CSA/UKCA certifications as per customer requirement

Vacuum Pumps
Wet Grinders
Sewing Machines
Machine Tools
Box Strapping Machines
Floor Polishers
Pouch Making Machines
Printing Presses
Sugar Cane Crushers
Jewellery Making Machines
Room Coolers
Needle Vibrators
Commercial Air-conditioning
Poultry Fan
Monkey Lift
Milking Machines
Paint Mixer
Gear Box
Dimond Polisher
Atta Chakki
Wood Cutter & Wood Planner
Air Compressor
Chaff Cutter
Supari Polishing & Cutting
Lawn Mover
Apple Grader

Permanently lubricated ball bearings with C2 or C3 clearances.
All standard motors are continuously rated to comply with performance standards. Special motors for cyclic or short-time duties can also be offered against specific applications. Enclosures include drip-proof (DP), totally enclosed (TE), totally enclosed fan-cooled (TEFC) and air-over motors (AOM). Totally Enclosed Non-Ventilated & Totally Enclosed Fan Cooled.
Customizable options include special shaft materials and tailored voltage/frequency motors
Enclosures : Sheet metal, CI Casting & Aluminum Casting body construction
Insulation class : B, F or H as per customer requirement.
Field-proven centrifugal gear is used for trouble-free operation. The open circuiting switch has sintered contact/s consisting of silver alloy and copper. These contacts have excellent anti-weld properties and can safely rupture heavy currents.

Exceptional Build Quality

Crafted from high-grade cast iron or aluminium, Godrej FHP Motors offer exceptional robustness and extended service life. The powder-coated finish provides additional protection against corrosion, while the sealed, totally enclosed fan-cooled (TEFC) design minimizes ingress of dust and moisture, adhering to IP55 standards.

Superior Performance and Efficiency

These motors deliver high starting torque and sustained output power (0.18 - 2.2 kW), supporting applications that require reliable, efficient performance. The advanced insulation (Class B/F) and double sealed ball bearings guarantee smooth, quiet, and consistent operation for continuous, S1 duty cycles in harsh environments.

Versatile Industrial Applications

From pumps and compressors to textile and packaging machinery, Godrej FHP Motors are suitable for a wide array of industrial and commercial uses. Their compact design, high operational efficacy, and customizable features such as terminal box or flying leads make integration seamless for various engineering requirements.

FAQ's of Godrej FHP Motors:

Q: How do I select the right Godrej FHP Motor for my application?

A: Selecting the ideal Godrej FHP Motor depends on your required power output, operational speed, voltage, and specific application needs such as machinery, pumps, compressors, or packaging. With frame sizes ranging from 56 to 90S, and power ratings from 0.25 to 3 HP, there is a model fit for most industrial uses. Assess your torque, mounting type, and environmental conditions for optimal selection.

Q: What are the major benefits of using a Godrej FHP Motor?

A: Godrej FHP Motors offer high starting torque, robust construction, compact size, and high operational efficiency. The IP55 rating ensures protection against dust and moisture, while the low noise (<70 dB) and vibration levels contribute to smoother, quieter performance. With a wide temperature tolerance and high reliability, these motors enhance uptime and reduce maintenance costs.

Q: When and where can Godrej FHP Motors be used?

A: These motors are suitable for continuous S1 duty cycle applications in industrial settings such as machinery, pumps, compressors, textile equipment, and packaging units. Their design enables operation in ambient temperatures from -15C to +40C and humid conditions up to 90% RH, making them versatile for various Indian and global industries.

Q: What process ensures the durability of Godrej FHP Motors?

A: Godrej FHP Motors are constructed with high-grade materials and finished with powder coating for corrosion resistance. The use of aluminium die-cast rotors and double sealed ball bearings further enhances their durability, while strict compliance with IS:996 and IS:325 standards guarantees long-term reliability in demanding environments.

Q: How does thermal protection work in these motors?

A: Thermal protection is available upon request and is designed to automatically shut down the motor if it overheats, preventing damage and ensuring safety during operation. This feature is particularly useful for applications that involve continuous or heavy-duty use.

Q: What mounting options are available for these motors?

A: Godrej FHP Motors offer flexible mounting choices, including foot and flange types, enabling versatile installation in a wide variety of machines. This adaptability simplifies integration into existing systems or new projects.
