Siemens LOGO 6ED1052-1CC08-0BA2

Siemens LOGO 6ED1052-1CC08-0BA2 Specification

Panel Type
DIN Rail Mount

Rated Current
Approx. 0.3 A (relay output)

Operating Voltage
12/24 V DC

Cooling System
Natural convection

Rated Insulation Voltage
DC 500 V

Features
Removable terminals, backlit display, programmable via LOGO! Soft Comfort, integrated clock

Protection Level
IP20

Protection Class
Class II

Components
Integrated display, 8 digital inputs, 4 digital outputs

Base Material
Polycarbonate

Way
Single module

Control System
Microcontroller-based

Connectivity Type
Ethernet (optional via expansion), none onboard

Current Rating
0.3 A

Rated Operation Voltage
12/24 V DC

Cover Material
Polycarbonate

Cabinet Material
Plastic (housing)

Thickness
70 mm (Depth)

Product Type
Programmable Logic Controller (PLC)

Material
Plastic / Polycarbonate (housing)

Surface Finish
Matte

Standard
IEC/EN 61131-2

Surface Color
Grey

Rated Voltage
12/24 V DC

Maximum Output Current
0.3 A per output

Dimension (L*W*H)
90 mm x 72 mm x 55 mm

Application
Automation & Control Systems

IP Rating
IP20

Display Type
LCD (integrated)

Output Specification
4 relay outputs

Data Retention
Typically 480 hours (RAM with battery)

Memory Capacity
200 blocks max. program size

Weight
Approx. 0.3 kg

Expansion Modules Supported
Yes, for additional I/O or communication

Power Consumption
Typically 3.8W

Ambient Temperature Range
0C to +55C (operation)

Mounting Type
35 mm DIN rail

Time Switch/Clock
Integrated

Programming Interface
PC cable (USB or Ethernet with adapter)

Input Specification
8 digital inputs (4 can be used as analog, 0-10V)

Display Resolution
6-line, 16 characters each

Siemens LOGO 6ED1052-1CC08-0BA2 Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
1 Week

About Siemens LOGO 6ED1052-1CC08-0BA2

LOGO! 24CE, logic module, display power supply / I/O: 24 V/24 V/24 V trans., 8 DI (4 AI)/4 DO, memory 400 blocks, modularly expandable, Ethernet integrated web server, data log, user-defined web pages, standard microSD card for LOGO! Soft Comfort V8.4 or higher, older projects executable cloud connection, MQTT in all LOGO! 8.4 basic units

Compact Design Meets Versatile Control

With its compact dimensions (90 x 72 x 55 mm) and a DIN rail mounting approach, the Siemens LOGO! 6ED1052-1CC08-0BA2 fits seamlessly into control panels for automation systems. Its integrated backlit LCD display and removable terminals provide ease of operation and installation, while the 200-block memory supports complex logic programs.

Flexible I/O and Programming Interface

The module offers 8 digital inputs-4 of which can be configured as analog (0-10V)-and 4 relay outputs for flexible process management. Programming and monitoring are straightforward with LOGO! Soft Comfort software, connected via USB or Ethernet (adapter required). Expansion modules enable further customization to suit growing system needs.

Reliable Performance and Built-in Features

Operating on 12/24 V DC and designed to IEC/EN 61131-2 standards, this logic module provides robust performance. Integrated features such as a real-time clock, battery-backed data retention (up to 480 hours), and a backlit display help ensure smooth and efficient automation.

FAQ's of Siemens LOGO 6ED1052-1CC08-0BA2:

Q: How can I program the Siemens LOGO! 6ED1052-1CC08-0BA2 module?

A: Programming is accomplished using LOGO! Soft Comfort software, with connection through a USB or Ethernet cable (when using the appropriate adapter). You can develop, simulate, and load your control program-up to 200 memory blocks-directly to the module for reliable automation.

Q: What types of input signals are supported by this module?

A: The module provides 8 digital inputs, of which 4 can be configured for analog input (0-10V). This versatility enables it to process digital on/off signals and analog values such as sensor outputs, allowing for flexible automation solutions.

Q: Where is the Siemens LOGO! module typically installed?

A: Installation is on a 35 mm DIN rail inside control cabinets, making it suitable for industrial and commercial automation, such as lighting control, pump management, HVAC systems, and more.

Q: What is the process for expanding I/O or communication capabilities?

A: Expansion is straightforward: simply attach compatible expansion modules to the base unit for additional digital/analog inputs, outputs, or communication interfaces, allowing the system to adapt to growing or changing requirements.

Q: When should the LOGO! module's data retention feature be considered?

A: The integrated RAM with battery backup provides data retention for up to 480 hours during power losses. This ensures your logic programs and timers are safeguarded against short-term outages, important in critical automation tasks.

Q: What are the benefits of using the integrated time switch and clock?

A: The built-in clock and time switch enable the automation of time-dependent operations-like scheduling device outputs for specific times-without the need for additional controllers, reducing hardware cost and simplifying automation projects.
