Siemens CPU 1511C-1 PN 6ES7511-1CL03-0AB0

Siemens CPU 1511C-1 PN 6ES7511-1CL03-0AB0 Specification

Panel Type
DIN Rail Mounted

Rated Insulation Voltage
DC 50 V

Base Material
Polycarbonate, Metal

Protection Class
Class III

Operating Voltage
19.2-28.8 V DC

Components
CPU, onboard I/O, communication interfaces

Protection Level
IP20

Thickness
120 mm

Features
Integrated inputs/outputs, high-speed processing, PROFINET support, compact design

Cabinet Material
Polycarbonate, Metal

Way
Modular

Cover Material
Polycarbonate

Control System
SIMATIC S7-1500

Rated Current
1.5 A

Connectivity Type
PROFINET, Ethernet

Cooling System
Natural air cooling

Current Rating
Max 1.5 A

Rated Operation Voltage
24 V DC

Product Type
Programmable Logic Controller (PLC) CPU Module

Material
Plastic, Metal

Surface Finish
Matte

Standard
IEC 61131-2

Surface Color
Grey

Rated Voltage
24 V DC

Frequency (MHz)
250 MHz

Maximum Output Current
0.5 A per output

Dimension (L*W*H)
129 mm x 35 mm x 147 mm

Application
Automation Control Systems, Process Control

IP Rating
IP20

Display Type
LED

Order Number
6ES7511-1CL03-0AB0

Communication Ports
2 x PROFINET (RJ45), 1 x USB

Integrated Digital Inputs
16

Permissible Humidity
5% to 95%, non-condensing

Redundancy
No

Input Supply Voltage Range
DC 19.2-28.8 V

Mounting Type
DIN Rail

Backplane Bus
Yes, for module extensions

Real Time Clock
Yes, buffered

Firmware Upgradeable
Yes

Storage Temperature
-40C to +70C

Program/Data Memory
1 MB/5 MB

Integrated Digital Outputs
16 (source)

Inrush Current
Up to 13 A

Operating Temperature
0C to +60C

Password Protection
Yes

Siemens CPU 1511C-1 PN 6ES7511-1CL03-0AB0 Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
2 Week

About Siemens CPU 1511C-1 PN 6ES7511-1CL03-0AB0

6ES7511-1CL03-0AB0

CPU 1511C-1 PN, 300KB Prog., 1,5MB Data

SIMATIC S7-1500 compact CPU CPU 1511C-1 PN, central processing unit with 300 KB work memory for program and 1.5 MB for data, 16 digital inputs, 16 digital outputs, 5 analog inputs, 2 analog outputs, 6 high-speed counters, 4 high-speed outputs for PTO/PWM/frequency output 1st interface: PROFINET IRT with 2-port switch, 6 ns bit performance, including front connector push-in, SIMATIC Memory Card required

Robust Performance & Integrated I/O

The CPU 1511C-1 PN delivers swift response times and seamless control with its powerful 250 MHz processor and onboard inputs/outputs (16 DI/16 DO). Its built-in memory and fast processing ensure efficient data handling, ideal for complex automation requirements in industrial environments.

Flexible Communication & Expansion

Equipped with two PROFINET (RJ45) ports and a USB interface, this controller supports smooth networking and device integration. Its modular design and backplane bus enable easy attachment of additional modules, making it scalable for future system upgrades.

Reliable Operation in Demanding Conditions

With an operating temperature range of 0C to +60C, storage from -40C to +70C, and humidity tolerance up to 95% (non-condensing), the unit is built for reliability. The sturdy polycarbonate-metal housing fits DIN rail panels, ensuring lasting protection in industrial settings.

FAQ's of Siemens CPU 1511C-1 PN 6ES7511-1CL03-0AB0:

Q: How can I upgrade the firmware of the Siemens CPU 1511C-1 PN?

A: Firmware upgrades can be performed via the USB port or PROFINET interfaces using Siemens engineering software (such as TIA Portal). Ensure the CPU is powered on and follow the guided software instructions for safe and effective firmware updates.

Q: What are the safety and environmental operating limits for this controller?

A: The CPU 1511C-1 PN operates reliably between 0C and +60C, with storage allowed from -40C to +70C. It sustains humidity levels from 5% to 95%, as long as conditions are non-condensing. The device adheres to IP20 protection (solid objects >12 mm, no moisture protection) and IEC 61131-2 standards.

Q: Where is this CPU typically installed, and what is its mounting method?

A: This CPU is designed for DIN rail mounting inside automation panels or electrical cabinets, simplifying installation and facilitating integrated process control in various industrial environments.

Q: What integrated connectivity options does the CPU offer for communication and networking?

A: The unit features two PROFINET (RJ45) ports for Ethernet-based communication and a USB port for direct connections. These interfaces enable communication with other SIMATIC modules, HMIs, and external devices, supporting scalable automation networks.

Q: What is the main benefit of using the CPU 1511C-1 PN in process automation?

A: The CPU's high-speed processing, integrated I/O, and versatile expansion options provide a compact yet powerful solution, enabling precise, reliable control while streamlining panel space and minimizing system complexity.

Q: How does the CPU ensure data and system security?

A: It features password protection to safeguard configuration and operation. Additionally, the device has a buffered real-time clock to maintain time data during power loss, further enhancing operational integrity.
