ABB Gauge pressure transmitter PGS300

ABB Gauge pressure transmitter PGS300 Specification

Features
Local LCD indicator (optional), Maintenance-free, Compact design, Corrosion-resistant, Explosion-proof version available

Inlet/Outlet
1/2 inch NPT (f) process connection

Mounting Type
Direct or manifold mounting

Theory
Pressure Transmitter

Control System
HART communication protocol

Working Temperature
-40 to +85 C (ambient)

Material
Stainless Steel 316L for wetted parts, Aluminum alloy housing

Structure
Two-wire, compact body, digital display (optional)

Power
4-20 mA loop-powered (no external power required)

Standard
CE, ATEX, IECEx, SIL2 certified

Pressure
0-600 bar (model specific)

Usage
Industrial pressure measurement

Application
Liquid, gas and steam pressure measurement in process industries

Seals Type
Viton, EPDM, FKM (depending on configuration)

Rangeability
Up to 100:1 (turndown)

Zero/Span Adjustment
Local push button or remote configuration

Measuring Principle
Piezoresistive sensor (Gauge measurement)

Process Connection Material
SS316L as standard, other on request

Ambient Humidity
0-100% RH non-condensing

Accuracy
Up to 0.2% of span

Response Time
< 100 ms

Weight
Approx. 1.5 kg

Output Signal
4-20 mA, HART digital signal

Ambient Temperature Limits
-40 to +85 C

Enclosure Protection
IP67/NEMA 4X

Power Supply
10.5 to 36 VDC

Explosion Protection
Ex d ia IIC T6 Gb (with relevant models)

Wetted Parts Material
SS 316L, Hastelloy C (optional)

Display
Optional backlit LCD

ABB Gauge pressure transmitter PGS300 Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
1 Week

About ABB Gauge pressure transmitter PGS300

The all rounder gauge pressure transmitter PGS300 represents the latest evolutionary step in the wide ABB pressure transmitters portfolio.

With the new Backlight display and optional Bluetooth, Digital Advanced Diagnostic feature and the QR code ensure a top-level usability experience.

Users can easily find the right application solution for their measurement needs with an excellent precision for pressure, level and flow measurements with advanced materials availability to withstand highly critical process fluids and hydrogen permeation condition (H-Shield).

The PGS300 have a straightforward accuracy performance level +/- 0.055% of span, full process compatibility to highest industry standard (e.g. NACE, ASME, etc.), manifolds M26 mounting option and combined multiple certifications (i.e. ATEX/IECEx/CSA North America and others).

SIL 2/3 certificate (COMING SOON) according to IEC 61508 standaRd for use in safety instrumented systems for SIL2 applications in a single transmitter configuration (1oo1) and for SIL3 applications in a redundant configuration (1oo2).

PGS300 features WirelessHART (COMING SOON) communication protocol allowing the addition of pressure measurement points throughout your operation. You can now monitor hard-to-reach locations and keep your employees out of dangerous and hazardous areas. The transmitters have a battery life of about 10 years at 32 sec update rates, delivering a very cost-effective and reliable solution to monitor your process assets.

Shorten installation times by eliminating complex wired infrastructures, and lower overall implementation costs of process measurement, with ABB wireless devices featuring WirelessHART communications Measurement made easy.

The PGS300 with Modbus (COMING SOON) protocol of communication provides the user precise measurements of gauge pressure and optional process temperature (the latter by means of an externally connected Pt100 resistance temperature detector) in a single device. Information is available to any host device that can communicate using Modbus protocol.

Data

Base accuracy : 0.055% of calibrated span
Span limits: 0.2 ... 60000 kPa; 0.8 in. H2O ... 8700 psi

Output signal: Multiple protocol availability offering interchangeability and transmitter upgrade capabilities
4 to 20 mA, HART - Including Easy Set up

Modbus RS 485 (COMING SOON)

Low-power consumption 1 to 5 V DC (COMING SOON)

WirelessHART (COMING SOON)

Easy local configuration via keys on LCD indicator

Backlit display with optional Bluetooth (COMING SOON)
Conforms to SIL2 / SIL3 acc. to IEC 61508 (PENDING)
Full compliance with PED Category III

Advanced Measurement Technology

The PGS300 is powered by a piezoresistive sensor, enabling highly accurate gauge pressure readings even in demanding industrial applications. Its digital output, combined with HART communication, ensures seamless system integration and real-time data monitoring. Certified to CE, ATEX, IECEx, and SIL2 standards, it adheres to global safety and quality requirements.

Rugged Construction and Versatile Installation

Designed for harsh industrial environments, the PGS300 features an IP67/NEMA 4X enclosure and is available with explosion-proof certification for hazardous areas. The compact, corrosion-resistant housing and SS316L wetted parts ensure extended operational life. Flexible direct or manifold mounting options suit a wide range of installations across various process industries.

User-Friendly Operation and Maintenance

The transmitter offers easy local zero and span adjustment via push buttons or remote HART configuration. Its optional backlit LCD display provides clear readings, while the maintenance-free design reduces downtime. Fast response time (<100 ms) and turndown up to 100:1 enable precise and adaptable pressure monitoring.

FAQ's of ABB Gauge pressure transmitter PGS300:

Q: How do I adjust the zero and span of the ABB PGS300 pressure transmitter?

A: You can adjust the zero and span directly on the device using the local push buttons located on the transmitter, or remotely via HART communication protocol, allowing flexible configuration to meet your application needs.

Q: What are the main benefits of using the PGS300 in process industries?

A: The PGS300 offers high accuracy (up to 0.2% of span), fast response, maintenance-free operation, and a compact, corrosion-resistant design. Its explosion-proof and IP67/NEMA 4X protected housing ensures reliable performance in challenging environments, making it highly beneficial for industrial applications.

Q: When should I choose the optional backlit LCD display?

A: The optional backlit LCD display is recommended when you need immediate, on-site visual confirmation of process pressure. It is particularly useful in environments with low lighting or when quick readings are required for maintenance or operational checks.

Q: Where can the PGS300 pressure transmitter be installed?

A: The PGS300 can be installed directly on process lines or mounted on manifolds, thanks to its compact body. Its IP67/NEMA 4X and explosion-proof certifications make it suitable for installation in a wide range of industrial settings, including hazardous areas.

Q: What is the measurement range and accuracy of the PGS300?

A: The PGS300 supports pressure ranges up to 600 bar depending on the model, with an accuracy of up to 0.2% of span. It also features a rangeability (turndown) of up to 100:1, enabling precise measurement across various process conditions.

Q: Which process connections and materials are available for the PGS300?

A: Standard process connections include 1/2 inch NPT (female) with SS316L as the standard wetted material. Other materials, such as Hastelloy C, are available upon request, making the PGS300 adaptable to a variety of process media.

Q: What communication and power options does the PGS300 support?

A: The transmitter uses a 4-20 mA current loop (loop-powered, requiring no external power supply) and supports HART digital communication, facilitating integration with modern control systems for advanced diagnostics and remote configuration.
