Siemens CPU1214c 6ES7214-1AH50-0XB0

Siemens CPU1214c 6ES7214-1AH50-0XB0 Specification

Way
Compact

Panel Type
DIN Rail Mountable

Cabinet Material
Plastic housing

Protection Class
Class I

Operating Voltage
DC 24V

Protection Level
IP20

Cover Material
Polycarbonate

Control System
Micro Automation

Rated Current
2A per group

Rated Insulation Voltage
500V AC

Connectivity Type
Ethernet, USB, RS485

Rated Operation Voltage
DC 24V

Features
Integrated IO, High-speed processing, Compact design

Cooling System
Natural air cooling

Components
CPU, Digital Inputs, Digital Outputs, Communication Port

Thickness
70 mm

Current Rating
0.5A (per channel)

Base Material
Industrial-grade plastic

Product Type
PLC CPU Controller

Material
Plastic, Metal

Surface Finish
Matte

Standard
IEC 61131-2

Surface Color
Grey

Rated Voltage
24V DC

Frequency (MHz)
50/60 Hz

Maximum Output Current
0.5A (per output)

Dimension (L*W*H)
130 x 100 x 75 mm

Application
Industrial Automation

IP Rating
IP20

Display Type
LED status indicators

Input Points
14 Digital (24V DC)

Mounting
35mm DIN rail mount

Output Points
10 Digital (Relay/Transistor)

Programming Software
TIA Portal

Weight
0.48 kg

Program Memory
100 KB

Data Memory
32 KB

Approvals/Certifications
CE, cULus, EAC

Operating Temperature
0C to +55C

Communication Port
PROFINET (Ethernet), USB, RS485 (Modbus RTU)

Scan Time per Instruction
~0.08s/bit

Siemens CPU1214c 6ES7214-1AH50-0XB0 Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
1 Week

About Siemens CPU1214c 6ES7214-1AH50-0XB0

6ES7214-1AH50-0XB0

CPU 1214C, DC/DC/DC, 14DI/10DO
SIMATIC S7-1200 G2: compact CPU 1214C DC/DC/DC; power supply: DC 20.4-28.8 V DC; onboard I/O: 14x DI 24 V DC; 10 DO 24 V DC; memory: program 250 KB data: 750 KB, retentivity: 20 KB

Integrated IO and High-Speed Performance

The CPU1214C comes with a combination of 14 digital input points and 10 digital output points which can be configured for relay or transistor operation. With a swift program scan time of approximately 0.08 seconds per bit, this controller ensures responsive and efficient processing, making it suitable for time-sensitive automation tasks.

Versatile Connectivity and Communication

Equipped with PROFINET (Ethernet), USB, and RS485 (Modbus RTU) communication ports, the Siemens CPU1214C supports seamless integration into modern industrial networks. This flexibility allows it to connect effortlessly to a variety of automated systems and devices, simplifying automation setup and expansion.

Robust, Compact Design for Industrial Applications

Constructed with industrial-grade plastic and metal, the CPU1214C is protected by a matte-finished polycarbonate cover and meets IP20 standards. Designed to mount easily on 35mm DIN rails, it operates reliably in temperatures from 0C to +55C, making it an ideal choice for space-constrained control panels and demanding environments.

FAQ's of Siemens CPU1214c 6ES7214-1AH50-0XB0:

Q: How do I set up and use the Siemens CPU1214C PLC in my automation project?

A: To set up the CPU1214C, mount it on a standard 35mm DIN rail and connect your 24V DC power supply. Connect inputs and outputs as required, and use PROFINET (Ethernet), USB, or RS485 (Modbus RTU) ports for programming and communication. Programming is done with the TIA Portal software, enabling you to configure logic, IO assignments, and networking.

Q: What are the main benefits of using the Siemens CPU1214C controller?

A: The CPU1214C offers a compact footprint, integrated digital IO, and high-speed processing (~0.08s/bit), making it ideal for space-restricted panels and systems requiring fast, reliable control. Its versatile communication ports support integration into virtually any modern industrial automation setup.

Q: Where can I deploy this PLC, and what kinds of environments is it suitable for?

A: This controller is designed for industrial automation, providing reliable operation in environments between 0C and +55C. The IP20 rating makes it ideal for use inside control cabinets in manufacturing lines, material handling systems, and process automation applications.

Q: What process does the Siemens CPU1214C follow to ensure reliable data handling?

A: With 100 KB of program memory, 32 KB data memory, and compliance with IEC 61131-2, the CPU1214C reliably executes control instructions at high speed while providing robust data integrity and stability for automated processes.

Q: When should I choose the relay or transistor output type on this model?

A: Choose relay outputs if you need to switch AC or DC loads with electrical isolation, while transistor outputs are better for fast, high-frequency switching in DC circuits. The CPU1214C offers both, giving flexibility to match your application requirements.

Q: How does the CPU1214C ensure safe and efficient operation?

A: The PLC meets CE, cULus, and EAC standards, includes LED status indicators for easy diagnostics, and features a polycarbonate cover for physical protection. The rated voltage (24V DC), insulation voltage (500V AC), and IP20 rating further enhance its operational safety.

Q: What usage advantages do I get from the compact dimensions and design of the CPU1214C?

A: With dimensions of 130 x 100 x 75 mm and weighing only 0.48 kg, the CPU1214C installs easily in compact panels, saving valuable space and simplifying wiring and maintenance without sacrificing functionality.
