Siemens CPU 1517T-3 PN/DP 6ES7517-3TP00-0AB0

Siemens CPU 1517T-3 PN/DP 6ES7517-3TP00-0AB0 Specification

Cover Material
Plastic

Features
Integrated technology functions, high-speed processing, extensive communication interfaces

Rated Current
--

Control System
SIMATIC S7-1500 T-CPU

Components
CPU, integrated inputs/outputs, communication interfaces

Connectivity Type
PROFINET, PROFIBUS, Ethernet

Protection Class
Class I

Base Material
Plastic

Rated Operation Voltage
DC 20.4-28.8 V

Cabinet Material
--

Current Rating
--

Panel Type
--

Rated Insulation Voltage
--

Operating Voltage
24 V DC

Thickness
--

Protection Level
IP20

Cooling System
Natural convection

Product Type
Programmable Logic Controller (PLC) CPU

Material
Plastic and Metal Components

Surface Finish
Matte

Standard
IEC 61131, CE, UL, cUL

Surface Color
Grey

Rated Voltage
DC 24 V

Frequency (MHz)
600 MHz (Processor clock speed)

Maximum Output Current
--

Dimension (L*W*H)
147 x 35 x 129 mm

Application
Industrial automation, motion control, machinery

IP Rating
IP20

Display Type
LCD display

Number of Communication Interfaces
3 (2x PROFINET, 1x PROFIBUS)

Certificates
CE, UL, cULus, RCM

Operating Temperature
0C to 60C

Mounting Type
DIN rail

Relative Humidity
5% to 95% (non-condensing)

Power Consumption
approx. 30 W

Data Backup
Retentive memory for important process data

PLC Family
SIMATIC S7-1500T Series

Article Number
6ES7517-3TP00-0AB0

Technology Functions
Motion control, camming, gearing, PID control, precise positioning

Memory Size
8 MB work memory, 256 KB load memory for technology objects

Siemens CPU 1517T-3 PN/DP 6ES7517-3TP00-0AB0 Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
2 Week

About Siemens CPU 1517T-3 PN/DP 6ES7517-3TP00-0AB0

6ES7517-3TP00-0AB0

CPU 1517T-3 PN/DP, 3MB prog./8MB data

SIMATIC S7-1500T, CPU 1517T-3 PN/DP, Central processing unit with work memory 3 MB for program and 8 MB for data, 1st interface: PROFINET IRT with 2-port switch, 2nd interface, Ethernet, 3rd interface, PROFIBUS, 2 ns bit performance, SIMATIC Memory Card required

Advanced Motion Control and Technology Functions

The CPU 1517T-3 PN/DP excels in delivering precise motion control, incorporating functions such as camming, gearing, and PID control. These features make it particularly suitable for machinery needing accurate coordination and flexible automation strategies. The integrated technology objects enhance process versatility and reduce overall engineering time.

Robust Communication and Connectivity

Equipped with two PROFINET and one PROFIBUS communication interfaces, this CPU ensures simple integration into complex industrial networks. These high-speed interfaces enable fast data transfer and reliable communication with both decentralised peripherals and higher-level supervisory systems, supporting a wide range of industrial automation applications.

Reliability and Data Protection

Designed for critical process control, the CPU's retentive memory safeguards essential process data even during power disruptions. Its robust construction includes an IP20 protection rating and compliance with international certifications like CE, UL, and cUL, ensuring dependable operation in diverse industrial settings.

FAQ's of Siemens CPU 1517T-3 PN/DP 6ES7517-3TP00-0AB0:

Q: How can the Siemens CPU 1517T-3 PN/DP be integrated into existing industrial automation systems?

A: The CPU supports integration via PROFINET and PROFIBUS interfaces, allowing it to connect easily with other SIMATIC devices, field equipment, and supervisory systems. Its compatibility with standard protocols ensures seamless incorporation into both new and legacy architectures.

Q: What are the main advantages of using this CPU for motion control applications?

A: Its advanced motion control functions-such as camming, gearing, and precise positioning-enable highly coordinated, synchronized movement in automated machinery. This reduces engineering complexity, increases system efficiency, and delivers superior control for demanding automation needs.

Q: When should I utilize the retentive memory feature of this CPU?

A: Use retentive memory to store important process data that must persist through power outages or system restarts. This ensures critical parameters and configurations are not lost, supporting safe and reliable plant operation.

Q: Where can the CPU 1517T-3 PN/DP be mounted in the control cabinet?

A: The CPU is designed for DIN rail mounting, facilitating straightforward installation in a standard control cabinet. Ensure adequate ventilation for natural convection cooling as specified in installation guidelines.

Q: What process does the CPU follow for precise position control?

A: Its integrated technology functions handle calculations for position, velocity, and synchronization tasks directly in the PLC. Motion axes and parameters are configured in the TIA Portal engineering software, allowing for rapid setup and adjustment.

Q: How can users benefit from the CPU's multiple communication interfaces?

A: The dual PROFINET and single PROFIBUS interfaces allow simultaneous communication with various devices, enabling flexible network structuring, rapid data exchange, and easy expansion without reducing system performance.
