Siemens SINAMICS V20 6SL3210-5BE17-5UV1

Siemens SINAMICS V20 6SL3210-5BE17-5UV1 Specification

Control System
V/f Control

Cover Material
Plastic

Cabinet Material
Plastic/Sheet Metal

Features
Energy Saving, Quick Commissioning, Robust Design

Current Rating
17.5A

Cooling System
Forced Air Cooling

Thickness
Approximately 200 mm depth

Way
3 Phase

Rated Insulation Voltage
500V

Rated Current
17.5A

Components
Integrated Keypad, Terminal Blocks, Built-in Braking Chopper

Rated Operation Voltage
400V AC

Protection Level
IP20

Operating Voltage
380-480V AC

Connectivity Type
USS/Modbus RTU via RS485

Protection Class
Class I

Panel Type
Wall-Mounted/Panel Mountable

Base Material
Sheet Metal

Product Type
AC Drive (Variable Frequency Drive)

Material
Plastic / Metal (Hybrid construction as per Siemens standard)

Surface Finish
Matte

Standard
IEC/EN 61800-5-1

Surface Color
Grey

Rated Voltage
3AC 380-480V 10%

Frequency (MHz)
50/60 Hz

Maximum Output Current
17.5A

Dimension (L*W*H)
350mm x 150mm x 200mm

Application
Industrial motor control, Pumps, Fans, Conveyors

IP Rating
IP20

Display Type
LED/LCD Display

Power Rating
7.5 kW (10 HP)

Output Frequency
0-550 Hz

Enclosure Material
Plastic/Metal Combined

Overload Capability
150% for 60 seconds

Input Voltage Range
3AC 323-528V

Ambient Temperature Range
-10C to +60C (derating above 50C)

Mounting Type
Panel/Wall Mountable

Control Panel
Removable Operator Panel

Communication Protocols
USS/Modbus RTU

Short Circuit Protection
Yes, integrated

Braking Chopper
Integrated

Siemens SINAMICS V20 6SL3210-5BE17-5UV1 Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
1 Week

Siemens SINAMICS V20 6SL3210-5BE17-5UV1 About

6SL3210-5BE17-5UV1

SINAMICS V20, 3AC 400V 0.75kW UNFILTERED

SINAMICS V20 380-480 V 3 AC -15/+10% 47-63Hz rated power 0.75 kW with 150% overload for 60 sec. unfiltered I/O: 4 DI, 2 DO,2 AI, 1 AQ fieldbus: USS/MODBUS RTU with built-in BOP protection: IP20/ UL open size: A 90x150x145.5 (WxHxD) with integrated braking unit

Robust Industrial Drive for Enhanced Motor Control

Engineered to meet IEC/EN 61800-5-1 standards, the SINAMICS V20 offers reliable performance in harsh industrial settings. Its hybrid plastic and metal construction secures longevity and ruggedness. Built-in overload protection, short-circuit safety, and wide ambient temperature operation (-10C to +60C) make it a versatile solution for India's diverse industrial applications.

User-Friendly Operation and Quick Commissioning

The SINAMICS V20 provides swift and intuitive startup with its integrated keypad and removable operator panel. LED/LCD displays enable straightforward status monitoring. Its V/f control system, wall or panel mounting options, and flexible connectivity with USS/Modbus RTU ensure adaptability, while forced air cooling maintains stable operations.

FAQ's of Siemens SINAMICS V20 6SL3210-5BE17-5UV1:

Q: How is the SINAMICS V20 6SL3210-5BE17-5UV1 typically installed in an industrial setup?

A: The drive is designed for flexible installation, supporting both wall and panel mounting options. With panel type compatibility and a robust construction, it fits easily into existing control enclosures or directly onto walls, streamlining the integration process.

Q: What are the key benefits of using this drive for applications like pumps or conveyors?

A: Its energy-saving features, robust design, and built-in braking chopper optimize motor efficiency and minimize mechanical stress. These attributes are particularly advantageous in pump, fan, and conveyor operations that demand reliable speed control and operational cost savings.

Q: When should the removable operator panel be used?

A: The removable operator panel enables easy commissioning, parameter setting, and troubleshooting. It's especially useful during installation or maintenance, as it can be detached from the drive for convenient handheld operation or replaced if needed.

Q: Where can this variable frequency drive be used given its protection level and construction?

A: With an IP20 rating and hybrid plastic/metal build, the SINAMICS V20 is suitable for indoor environments where dust and water exposure are limited. Common applications include factories, warehouses, and process plants across India.

Q: What is the process for connecting the drive via USS or Modbus RTU protocols?

A: The drive supports connectivity through its RS485 interface, allowing seamless integration with control systems or PLCs using USS or Modbus RTU protocols. Configuration involves wiring the communication cables and setting the parameters via the keypad or operator panel.

Q: How does the built-in braking chopper enhance usage in dynamic applications?

A: The integrated braking chopper quickly dissipates excess energy during rapid deceleration, improving response times and ensuring safer operation, which is crucial for applications with frequent starts and stops such as conveyor systems.

Q: What features contribute to the SINAMICS V20's long-term durability?

A: The drive's hybrid plastic/metal construction, forced air cooling, and adherence to international standards (IEC/EN 61800-5-1) provide protection against physical and electrical stresses, enhancing longevity in demanding industrial environments.
