Mitsubishi FR-A840-03250-E2-60

Mitsubishi FR-A840-03250-E2-60 Specification

Rated Insulation Voltage
690V AC

Cabinet Material
Metal (rear), Plastic (front)

Connectivity Type
Ethernet, RS-485 Modbus

Protection Level
IP20

Cooling System
Forced Air Cooling

Features
Energy Saving, Auto-Tuning, Safety Stop, Removable Terminal Block

Operating Voltage
Three Phase 380-480V AC

Rated Current
325A

Control System
Vector Control, V/F Control

Rated Operation Voltage
400V AC

Cover Material
Plastic

Panel Type
Keypad Digital Panel

Base Material
Plastic

Current Rating
325A

Components
Integrated EMC filter, Cooling Fan

Protection Class
Class I

Product Type
Frequency Inverter (VFD)

Material
Plastic, Metal Components

Surface Finish
Matte

Standard
IEC/EN 61800-5-1

Surface Color
Grey

Rated Voltage
Three Phase 400V AC

Frequency (MHz)
0.2 to 400 Hz

Maximum Output Current
325A

Dimension (L*W*H)
470 x 420 x 350 mm

Application
Industrial Motor Control, Automation

IP Rating
IP20

Display Type
LCD Digital Display

Weight
Approx. 56 Kg

Compliance
CE, UL, cUL, RoHS

Ambient Temperature
-10C to +50C

Input Voltage Range
323 to 528V AC

Motor Capacity
160-220 kW

Noise Level
Less than 75 dB

Starting Torque
200% or higher

Mounting Type
Wall Mount, Panel Mount

Overload Capacity
150% for 60 seconds

Braking Unit
Built-in

Mitsubishi FR-A840-03250-E2-60 Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
4 Week

About Mitsubishi FR-A840-03250-E2-60

InverterAC w/o DC Choke;Pn:90-160kW;3x380-500V;In max:325A;(110kW;216A)IP00,ETH.

Series	FR-A800 PLUS SERIES
Type	FR-A800-CRN (FOR CRANES)
Minimum Rated Voltage (V)	380
Min. Permissible Voltage (V)	323
Maximum Rated Voltage (V)	500
Max. Permissible Voltage (V)	550
Current Type	AC
Phases	3
Rated Output Current SLD (A)	325
Rated Output Current LD (A)	260
Rated Output Current ND (A)	216
Rated Output Current HD (A)	180
Rated Motor Capacity ND (kW)	110
Rated Motor Capacity HD (kW)	90
Frequency Range (Hz)	0,2590
Control Method	VECTOR CONTROL (WITH FR-A8AP), V/F CONTROL, SOFT-PWM/HIGH FREQUENCY PWM, REAL SENSORLESS VECTOR CONTROL, PM SENSORLESS VECTOR CONTROL, MAGNETIC FLUX VECTOR CONTROL
Motor Type	INDUCTION MOTOR, PM MOTOR
Integrated EMC Filter	YES
Safe Torque Off (STO)	YES
Regenerative (4Q)	NO
Integrated DC Choke	NO
Display	FR-DU08
Display Type	5 DIGITS LED (12 SEGMENT)
PLC Function	YES
Program Memory	6K
Program Memory Unit	STEPS
Integrated Digital Inputs	12
Digital Outputs (Transistor)	5
Digital Outputs (Relay)	2
Integrated Analogue Inputs	3
Integrated Analogue Outputs	2
IO Type of Terminal Block	SPRING CLAMP
Expandable	YES
USB	1+1 MINI
Ethernet Port	1
Built-In Network	CC-LINK IE FIELD NETWORK BASIC, MODBUS/TCP, SLMP, iQSS
Leakage Current (mA)	35(DELTA) / 2(STAR)
Power Loss SLD (W)	3600
Power Loss LD (W)	2800
Power Loss ND (W)	2300
Power Loss HD (W)	1850
Standby Power Consumption (W)	75
Protection Class	IP00

Conformity

CE	COMPLIANT
UL/cUL	COMPLIANT
EAC	COMPLIANT
Shipping Approvals	ABS,BV,DNV GL,LR,NK
UKCA	COMPLIANT

Product Dimensions & Weight

Width (mm)	465
Height (mm)	740
Depth (mm)	360
Weight (kg)	71

Life Cycle

Serial No. on the Box	QR1

Campaigns

Selling Status	Standard

Product Packaging

Cardboard (g)	8500
Other paper (g)	0
Aluminum (g)	0
Steel (g)	15
Styrofoam (g)	0
Other plastic (g)	80

Advanced Motor Control for Industrial Applications

The FR-A840-03250-E2-60 is tailored for challenging motor control environments. Its vector and V/F control systems deliver excellent start-up performance, with a starting torque of 200% or higher. The unit's overload capacity, energy-saving features, and auto-tuning capability ensure reliability and efficiency, making it ideal for automation and heavy-duty operations.

Versatile Mounting and Robust Construction

Designed for wall or panel mounting, this inverter accommodates diverse installation requirements. Its housing combines a sturdy plastic front and a metal rear for enhanced durability. With dimensions of 470 x 420 x 350 mm and an approximate weight of 56 kg, it remains compact while providing powerful industrial performance.

Comprehensive Protection and Global Certifications

The FR-A840-03250-E2-60 offers IP20 protection class I, and complies with CE, UL, cUL, RoHS, and IEC/EN 61800-5-1 standards. Integrated safety features, including a built-in braking unit, EMC filter, and forced air cooling, ensure secure, efficient, and stable operation in a broad temperature range from -10C to +50C.

FAQ's of Mitsubishi FR-A840-03250-E2-60:

Q: How is the Mitsubishi FR-A840-03250-E2-60 inverter installed in industrial settings?

A: This inverter supports both wall and panel mounting, allowing flexible installation depending on your control cabinet layout or available space. Its compact design and supplied accessories facilitate straightforward setup in most standard industrial environments.

Q: What are the key benefits of the built-in braking unit and integrated EMC filter?

A: The built-in braking unit enables the inverter to handle rapid deceleration and dynamic motor loads safely, preventing system wear and overheating. The integrated EMC filter reduces electrical noise, ensuring compliance with safety regulations and minimizing interference with other equipment.

Q: When should I use the energy-saving and auto-tuning features?

A: The energy-saving feature should be activated to reduce unnecessary power consumption during periods of variable loads, boosting operational efficiency. Auto-tuning is recommended during initial setup or when replacing motors, ensuring optimal drive performance and motor compatibility.

Q: Where is the Mitsubishi FR-A840-03250-E2-60 most commonly applied?

A: This inverter is widely used in industrial motor control and automation settings, such as manufacturing plants, conveyor systems, and high-capacity pump or fan operations due to its high power capacity and advanced features.

Q: What protection measures are integrated in this model?

A: The FR-A840-03250-E2-60 incorporates multiple protection mechanisms, including overload protection (150% for 60 seconds), IP20 enclosure, Class I insulation, forced air cooling, and a safety stop function. These features ensure safe and reliable operation in demanding environments.

Q: How does the inverter support connectivity and monitoring?

A: It is equipped with an LCD digital display panel and supports remote monitoring and control via Ethernet and RS-485 Modbus communication protocols, facilitating easy integration into modern industrial automation systems.
