Festo VSNC-FT-B52-D-G14-FN-1A1

Festo VSNC-FT-B52-D-G14-FN-1A1 Specification

Caliber
14 mm

Connection
G1/4 threaded ports

Structure
5/2-way, single solenoid valve

Channels
5/2

Pressure
2 to 10 bar

Material
Aluminum body, Polymer coil housing, NBR seals

Power
24V DC (electrical solenoid)

Media
Compressed air

Temperature of Media
-5C to +50C

Port Size
G1/4

Flange
Panel or sub-base mounting

Finish
Anodized

Application
Pneumatic automation control

Flow rate
1100 l/min (approx.)

Mounting Position
Any

Valve type
Solenoid actuated directional control valve

Switching time
<50 ms

Operating voltage
24 V DC

Actuation type
Electrical

Manual override
Yes, momentary and lockable

Protection class
IP65

Coil width
52 mm

Standard
NAMUR interface

Festo VSNC-FT-B52-D-G14-FN-1A1 Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
2 Week

About Festo VSNC-FT-B52-D-G14-FN-1A1

Technical Data

Valve function5/2 bistable
Type of actuationElectric
Construction width32 mm
Standard nominal flow rate (standardised to DIN 1343)1000 l/min
pneumatic working portNAMUR port pattern
Operating voltage24V DC
Operating pressure0.15 MPa ... 0.8 MPa
Operating pressure1.5 bar ... 8 bar
DesignPoppet seat
Certificate issuing authorityDNVGL-TAA000011J
Degree of protectionIP65 IP67 With plug socket To IEC 60529
Exhaust-air functionWith flow control option
Sealing principleSoft
Mounting positionoptional
Conforms to standardVDI/VDE 3845 (NAMUR)
Manual overrideDetenting Non-detenting
Type of pilotingPilot actuated
Pilot air supplyInternal
Flow directionNon-reversible
Symbol00991005
lapUnderlap
Signal status displayWith accessories
b value0.24
C value4.6 l/sbar
Switching time reversal16 ms
Duty cycle100%
Characteristic coil data24 V DC: 0.7 W
Permissible voltage fluctuations+/- 10 %
Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot mediumLubricated operation possible (in which case lubricated operation will always be required)
Corrosion resistance class CRC2 - Moderate corrosion stress
LABS (PWIS) conformityVDMA24364-B2-L
Media temperature-20 C ... 60 C
Ambient temperature-20 C ... 60 C
Product weight635 g
Electrical connectionType A To EN 175301-803
Type of mountingWith through-hole
Breather connectionNot ducted
Pneumatic connection, port 1G1/4
Pneumatic connection, port 2NAMUR port pattern
Pneumatic connection, port 3G1/4
Pneumatic connection, port 4NAMUR port pattern
Pneumatic connection, port 5G1/4
Note on materialsRoHS-compliant
Material sealsNBR
Material housingWrought aluminium alloy
Material screwsGalvanised steel

Reliable Pneumatic Control for Industrial Automation

Designed to meet strict industrial standards, the Festo VSNC-FT-B52-D-G14-FN-1A1 delivers stable performance in pneumatic automation tasks. With a sturdy anodized aluminum construction and advanced sealing, it ensures dependable operation from -5C to +50C. Its NAMUR interface standard streamlines installation and compatibility with panel or sub-base mounting. Suitable for applications across various industries, the valve facilitates efficient, responsive, and controllable airflow for complex automation processes.

Flexible and User-Friendly Features

This solenoid valve includes both momentary and lockable manual override options, giving operators enhanced control during setup and emergency situations. The coil's 52 mm width and protection class IP65 provide resilience in harsh, dusty, or wet environments. Thanks to universal mounting positions and G1/4 threaded ports, system integration is simplified, reducing installation time and effort. Its quick switching time of under 50 ms ensures fast pneumatic response.

FAQ's of Festo VSNC-FT-B52-D-G14-FN-1A1:

Q: How is the Festo VSNC-FT-B52-D-G14-FN-1A1 valve typically installed in automation systems?

A: This valve can be mounted in any position thanks to its universal design. It features both panel and sub-base mounting options, with G1/4 threaded ports, enabling flexible integration into diverse pneumatic setups.

Q: What benefits does the manual override feature provide for users?

A: The manual override, which supports both momentary and lockable operation, allows operators to manually actuate the valve for system testing, maintenance, or emergency intervention, enhancing overall safety and convenience.

Q: When should I use the Festo VSNC-FT-B52-D-G14-FN-1A1 in my pneumatic application?

A: This valve is ideal when you need fast, reliable airflow control with electrical actuation, especially where quick switching (under 50 ms), durable materials, and compatibility with NAMUR interfaces are required.

Q: Where can the Festo VSNC-FT-B52-D-G14-FN-1A1 valve be used?

A: It is suitable for a wide range of industrial environments, including manufacturing, packaging, and process automation, particularly where protection against dust and moisture (IP65) and robust operation are important.

Q: What process media is compatible with this solenoid valve?

A: The valve is designed specifically for compressed air, operating efficiently within temperature ranges of -5C to +50C and a pressure range from 2 to 10 bar, making it compatible with standard pneumatic systems.

Q: How does the valve's 5/2-way single solenoid structure function?

A: In this configuration, one solenoid shifts the valve to direct airflow between two outputs (5 ports, 2 positions), making it suitable for controlling double-acting pneumatic actuators and cylinders.
