Parker PVP16362R212

Parker PVP16362R212 Specification

Max Suction
0.8 bar

Features
High efficiency, compact design, long service life

Caliber
Variable displacement type

Discharge Pressure
Up to 320 bar

Noise Level
Low noise operation

Mounting Type
ISO flange mounting

Speed
Up to 1800 rpm

Inlet/Outlet
Standard hydraulic fittings

Control System
Hydraulic control

Head Size
Standard

Theory
Axial piston pump

Flow Rate
Up to 160 l/min

Working Temperature
-20C to +80C

Material
High-strength cast iron

Structure
Radial housing with swash plate design

Power
Dependent on drive motor (Hydraulic application)

Standard
Parker hydraulics standard

Pressure
Maximum 320 bar

Usage
Industrial hydraulic systems

Application
Mobile and industrial machinery

Suction Type
Hydraulic suction

Seals Type
High-performance elastomer

Priming
Self-priming design

Pump Type
Variable displacement axial piston pump

Capacity
Up to 163 cm/rev

Port Size
Customizable

Rotation Direction
Right (R)

Shaft Type
Splined shaft

Weight
Approx. 50 kg

Protection
Corrosion resistant paint

Model Number
PVP16362R212

Minimum Fluid Temperature
-20C

Recommended Viscosity Range
15100 mm/s

Maximum Fluid Temperature
up to 80C

Adjustment Mechanism
Load sensing and pressure compensator

Series
PVP163

Displacement
163 cm

Fluid Compatibility
Mineral oil-based hydraulic fluids

Parker PVP16362R212 Trade Information

Minimum Order Quantity
1 Unit

Delivery Time
3 Week

About Parker PVP16362R212

Specifications

Primary brand

Parker Hannifin

Main function

Hydraulic pump

Product series / family name

Pumps (hydraulic) > Variable displacement > Axial piston pumps > Medium pressure

Sub-range name

PVP series

Functions

Hydraulic variable volume piston pump

Design

SAE A 3/4" keyed shaft (CW rotation)
side ports
pressure-compensated
adjustable max. volume stop
single pump (no factory pre-assembly of multiple pumps)
hydraulic filtration (ISO) 16/13 - 18/15
Fluid optimum viscosity 17-180cSt (max. start-up is 1000cSt)

Flow

7.8gallons/min (GPM) at 21bar/300psi / 1800rpm
29.5L/min (LPM) at 21bar/300psi / 1800rpm

Pressure

250bar / 3600psi max. operating pressure

Rated power

13.1kW input power at 1800rpm

Rated power (HP)

17.5HP input power at 1800rpm

Rotational speed

600rpm min.
3000rpm max.

Connection type

1 x 3/4" SAE 4-bolt flange 3/8"-16 thread (code 61) inlet threaded port
1 x 3/4" SAE 4-bolt flange 3/8"-16 thread (code 61) outlet threaded port
2 x SAE-6 straight thread 9/16"-18UNC case drain threaded ports

Mounting mode

SAE A 2-bolt mounting flange

Material

cast Iron body
Nitrile NBR seals

Ambient air temperature for operation

-40F...+160F / -40C...+71 C

Order code / Manufacturer SKU

PVP16362R212

Manufacturer product status

Commercialized

Displacement volume

16cm3/rev. max. displacement
1in3/rev. max. displacement

Benefits

Durable variable volume hydraulic piston pumps for medium pressure applications
With a pressure rating of 3600psi and a wide range of controls PVP pumps are efficient and reliable
Flexible and high-performing
Increased productivity
Full power thru-shaft capability
Design flexibility
Wide range of controls
Ease of use
Replaceable bronze port plate and piston slipper plate
Two piece housing for ease of service
Metric pilot / shaft and ports available
High-strength cast-Iron housing for reliability and quiet operation
Optional inlet/outlet locations for ease of installation
Low noise levels - promote more comfortable operating environment
Fast response times

Built for Performance and Reliability

Crafted from high-strength cast iron and protected with corrosion-resistant paint, the Parker PVP16362R212 guarantees stability and lasting operation, even in rigorous environments. Its axial piston design and load-sensing adjustment mechanism deliver consistent, energy-efficient performance, minimizing operational noise and maximizing uptime for both mobile and industrial machinery.

Flexible Integration and Custom Features

This pump accommodates a variety of systems with its ISO flange mounting, standard hydraulic fittings, and customizable port sizes. The self-priming capability and robust sealing system ensure hassle-free installation and dependable function, making it a versatile solution for OEMs, exporters, and industrial users throughout India and beyond.

FAQ's of Parker PVP16362R212:

Q: How does the Parker PVP16362R212 adjust its flow and pressure during operation?

A: The pump features a load-sensing and pressure compensator adjustment mechanism, enabling it to automatically vary displacement in response to system demand. This ensures optimal flow and pressure while minimizing energy consumption and heat generation.

Q: What applications are most suitable for using the PVP16362R212 pump?

A: Primarily designed for mobile and industrial hydraulic systems, the PVP16362R212 excels in equipment such as construction machinery, material handling vehicles, and industrial presses where stability, high efficiency, and pressure control are essential.

Q: When should the Parker PVP16362R212 be chosen over a fixed displacement pump?

A: This model is ideal when variable flow rates are required, especially in systems where load conditions change frequently. Its variable displacement design allows the system to adapt dynamically, increasing efficiency and extending equipment life.

Q: Where can the Parker PVP16362R212 be installed within hydraulic systems?

A: Thanks to its ISO flange mounting and flexible fitting options, this pump can be integrated into a wide array of installations in both stationary and mobile machinery, supporting diverse OEM and retrofit projects.

Q: What process is involved in maintaining the Parker PVP16362R212?

A: Routine maintenance includes checking fluid levels, monitoring for leaks, ensuring clean hydraulic oil at recommended viscosity levels (15-100 mm2/s), and inspecting seals and fittings. Its design supports extended service intervals due to the use of high-performance elastomer seals and precision engineering.

Q: What are the usage benefits of the PVP16362R212 pump for operators?

A: Operators benefit from its high efficiency, low noise output, and long service life. The self-priming and corrosion-resistant features ensure reliable startup and endurance, while the advanced control system allows precise operation under variable load conditions.
