VZWM-L-M22C-G34-F4 Solenoid Valve

The VZWM-L-M22C-G34-F4 Solenoid Valve is a standard processing type valve suitable for industrial usage. The valve is made of brass material and can handle both liquid and gas media. With a weight of 1270 grams, this valve is considered to be of standard size. It has a two-way way type with a pressure range of 0.5 bar to 6 bar. This solenoid valve is designed to cater to different industrial applications that require high-quality valves that are durable and reliable.

• Design Diaphragm valve servo-controlled
• Type of actuation Electric
• Sealing principle Soft
• Mounting position Preferably vertical
• Type of mounting In-line installation
• Connection Process valve G3/4
• Electrical connection Solenoid coil type MD-... , coil can be ordered as an accessory
• Nominal size 27.5 mm
• Valve function 2/2-way, closed, monostable
• Flow direction Non-reversible
• Medium Compressed air to ISO 8573-1:2010 [7:4:4] Inert gases Water Neutral fluids
• Medium pressure,valve for liquid media 0.5 bar ... 6 bar
• Medium pressure,valve for gaseous media 0.5 bar ... 10 bar
• Pressure difference 0.5 bar
• Type of piloting Pilot actuated
• Symbol 00995681
• Max. viscosity 22 mm²/s
• Media temperature -10 °C ... 60 °C
• Media temperature for fluids 5 °C ... 50 °C
• Ambient temperature -10 °C ... 60 °C
• Flow rate Kv 8.5 m³/h
• Standard nominal flow rate (standardised to DIN 1343) 10000 l/min
• Switching time on 15 ms
• Switch-on time for fluids 400 ms
• Switching time off 12 ms
• Switch-off time for fluids 930 ms
• b value 0.5
• C value 39 l/sbar
• Note on materials RoHS-compliant
• LABS (PWIS) conformity VDMA24364 zone III
• Material housing Brass
• Material number housing 2.0402
• Material seals NBR
• Material plunger tube High-alloy steel
• Product weight 1270 g
• CE mark (see declaration of conformity) In accordance with EU Pressure Equipment Directive
• UKCA marking (see declaration of conformity) to UK Pressure Equipment Regulations
• Corrosion resistance class CRC 1 - Low corrosion stress
• Max. tightening torque for cover screw 30 Nm
• Max. tightening torque for connecting thread 200 Nm
• Max. tightening torque for coil fastening 0.5 Nm
