VZBA-1-4inch GG-63-T-22-F0304-V4V4T-PP15-R-90-C Ball Valve Actuator Unit

The VZBA-1-4inch GG-63-T-22-F0304-V4V4T-PP15-R-90-C Ball Valve Actuator Unit is a top-quality product that is suitable for use in industrial applications. This product is designed to work with medium pressure systems and is powered by pneumatic energy. It is made from cast iron, mild steel, and stainless steel materials, which ensure its durability and reliability over a long period of time. The surface of this product is powder-coated with a finish that is resistant to wear and tear, making it an excellent choice for use in harsh environments. This unit is a standard size, making it compatible with most industrial systems and applications.

• Design 2-way ball valve Semi-rotary drive
• Type of actuation Pneumatic
• Mounting position optional
• Type of mounting In-line installation
• Connection Process valve Rp1/4
• Switching position indicator Slot direction = flow direction
• Nominal size DN 8
• Operating pressure 6 bar ... 8.4 bar
• Nominal pressure PN 63
• Symbol 00991921
• Medium Compressed air to ISO 8573-1:2010 [-:-:-] Inert gases Water no water vapour Neutral fluids
• Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
• Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required)
• Media temperature -10 C ... 200 C
• Ambient temperature -10 C ... 80 C
• Flow rate Kv 7 m/h
• Max. surface temperature assembly TX
• explosion group assembly IIC, IIIC
• Note on materials RoHS-compliant
• LABS (PWIS) conformity VDMA24364 zone III
• Material housing High-alloy stainless steel
• Material number housing 1.4408
• Material seals PTFE PTFE reinforced
• Material ball High-alloy stainless steel
• Material number ball 1.4408
• Material shaft High-alloy stainless steel
• Material number shaft 1.4401
• Product weight 1450 g
• Explosion protection Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX)
• Explosion ambient temperature -10 C <= Ta <= +60 C
• Corrosion resistance class CRC 3 - high corrosion stress
