VMEF-RT-M32-M-G18 Roller Lever Valve

The VMEF-RT-M32-M-G18 Roller Lever Valve is a top-of-the-line industrial valve that is perfect for pneumatic systems. The valve is made of high-quality aluminum and is powder-coated, making it resistant to wear and corrosion. It has a pressure range of -0.095 MPa to 1 MPa, making it suitable for a wide variety of applications. The valves nominal size is 5.6 mm, and it is designed to be easy to install and operate. The roller lever mechanism ensures precise control over the valve, and the valves performance is reliable and consistent.

• Valve function 3/2-way, single solenoid
• Type of actuation Mechanical
• Construction width 20 mm
• Standard nominal flow rate (standardised to DIN 1343) 750 l/min
• pneumatic working port G1/8
• Operating pressure -0.095 MPa ... 1 MPa
• Operating pressure -0.95 bar ... 10 bar
• Design Roller lever Poppet seat
• Type of reset Mechanical spring
• Max. stroke limit (hard) 6.3 mm
• Nominal size 5.6 mm
• Instructions on use Risk of pinching
• Sealing principle Soft
• Mounting position optional
• Type of piloting Direct
• Flow direction Reversible
• Symbol 00991353
• Lap Zero overlap
• Max. actuating speed with lateral actuation 1.4 m/s
• Max. switching frequency 3 Hz
• Cam angle 30 deg
• Explosion protection Zone 1 (ATEX) Zone 2 (ATEX) Zone 21 (ATEX) Zone 22 (ATEX)
• Operating medium Compressed air to ISO 8573-1:2010 [7:-:-]
• Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required)
• Corrosion resistance class CRC 1 - Low corrosion stress
• LABS (PWIS) conformity VDMA24364-B1/B2-L
• Media temperature -10 °C ... 60 °C
• Ambient temperature -10 °C ... 60 °C
• Note on ambient temperature Influence of heat on wear
• Actuating force 35.2 N
• Product weight 209 g
• Type of mounting With through-hole
• Pneumatic connection, port 1 G1/8
• Pneumatic connection, port 2 G1/8
• Pneumatic connection, port 3 G1/8
• Note on materials RoHS-compliant
• Material mounting adaptor Galvanised steel
• Material seals NBR
• Material housing Anodised wrought aluminium alloy
