Directional Control On-off Valves

SIZE 3

DG4V-3 IS OUR D03/NG6 DIRECT-ACTING DIRECTIONAL  BANG BANG VALVE.

• SINGLE OR DOUBLE SOLENOID HIGH-RESPONSE VALVE

• VITON SEALS ARE STANDARD. NITRILE ARE AVAILABLE.

• RANGE OF COIL CONNECTORS INCLUDING DIN, DEUTSCH, AMP AND TERMINAL BOX

• HIGHER SUSTAINED MACHINE PRODUCTIVITY AND HIGHER UPTIME BECAUSE OF PROVEN FATIGUE LIFE AND ENDURANCE, TESTED OVER 20 MILLION CYCLES

SIZE 5

DG4V-4, DG4V-S4 AND DG4V-5 DIRECT OPERATED D05/NG10 VALVES.

• WET ARMATURE SOLENOIDS FOR QUIETER OPERATION AND LONG LIFE WITH NO DYNAMIC SEAL LEAKAGE

• TWO SOLENOID SIZES TO CHOOSE FROM FOR OPTIMUM PERFORMANCE AND COST SELECTION

DG3V-5, DG5V-5 SOLENOID/PILOT OPERATED D05/NG10 VALVES.

• ALL SPOOL TYPES HAVE BEEN DESIGNED TO PROVIDE GOOD LOW-SHOCK

• FAST-RESPONSE CHARACTERISTICS WHICH CAN BE ENHANCED BY AN OPTIONAL PILOT CHOKE MODULE

SIZE 7

DG3V-7, DG5V-7 SOLENOID/PILOT OPERATED D07/NG16 VALVES.

• MODELS INCLUDE SPRING OFFSET, SPRING CENTERED AND DETENTED VERSIONS

• DG5V VALVES CAN BE ARRANGED FOR INTERNAL OR EXTERNAL PILOT PRESSURE AND/OR DRAIN CONNECTIONS

• HIGH PRESSURE AND FLOW CAPABILITY FOR MAXIMUM COST-EFFECTIVENESS

• THE MANY OPTIONAL FEATURES, PARTICULARLY FOR DG5V VALVES,

• PERMIT MATCHING TO VIRTUALLY EVERY APPLICATION WITHIN THE VALVES POWER CAPACITY

SIZE 8

DG3V-8, DG5V-8 SOLENOID/PILOT OPERATED D08/NG25 VALVES.

• A MINI-SYSTEM CAPABILITY WITH WIDE VARIETY OF SPOOL AND SPRING ARRANGEMENTS, STROKE AND PILOT CHOKE ADJUSTMENTS, INTEGRAL CHECK VALVES AND PORT ORIFICES

• HIGH FORCE SOLENOIDS AND CENTERING SPRINGS ASSURE CONSISTENT SHIFTING

• OPTIONAL MAINSTAGE SPOOL POSITION MONITORING SWITCH (CE MARKED)

• ENDURANCE TESTED TO 10 MILLION CYCLES AND FATIGUE TESTED WITHOUT FAILURE TO ENSURE HIGHEST RELIABILITY

SIZE 10

DG3V-8, DG5V-8 SOLENOID/PILOT OPERATED D08/NG25 VALVES.

• A MINI-SYSTEM CAPABILITY WITH WIDE VARIETY OF SPOOL AND SPRING ARRANGEMENTS, STROKE AND PILOT CHOKE ADJUSTMENTS, INTEGRAL CHECK VALVES AND PORT ORIFICES

• HIGH FORCE SOLENOIDS AND CENTERING SPRINGS ASSURE CONSISTENT SHIFTING

• OPTIONAL MAINSTAGE SPOOL POSITION MONITORING SWITCH (CE MARKED)

• ENDURANCE TESTED TO 10 MILLION CYCLES AND FATIGUE TESTED WITHOUT FAILURE TO ENSURE HIGHEST RELIABILITY

• PLAIN, WATERPROOF, AND LOCKABLE MANUAL OVERRIDE OPTIONS ARE AVAILABLE TO FACILITATE SYSTEM TROUBLESHOOTING OR SERVICING.

M-SERIES

THIS MOBILE VERSION VALVES INCLUDE: DG4V-3M & DG4V-5M DIRECT-ACTING D03/NG06 VALVES.

• INTEGRATED DEUTSCH CONNECTORS PROVIDE BEST-IN-CLASS IP69K INGRESS PROTECTION PERFECT FOR APPLICATIONS REQUIRING HIGH PRESSURE WASHDOWN.

• PROPORTIONAL CONTROL AVAILABLE (KDG4V-3M)

• COIL RATINGS OF: 12 VDC, 24 VDC,28 VDC

• DIN CONNECTOR AVAILABLE

• ENDURANCE TESTED TO 10 MILLION CYCLES AND FATIGUE TESTED WITHOUT FAILURE TO ENSURE HIGHEST RELIABILITY
