ADN-12-5-A-P-A Compact Cylinder

The ADN-12-5-A-P-A Compact Cylinder is a hydraulic power operated structure made of high-quality steel. This compact cylinder is an ideal industrial tool that can fulfil heavy-duty tasks with ease. Its standard size makes it more accessible to use and store in any industrial setup. The cylinder is designed for smaller bore sizes and offers high reliability, making it a perfect fit for continuous cyclic operations. This compact cylinder is available with multiple stroke lengths, making it versatile to use. It is a durable product that guarantees excellent performance, and the steel material ensures longevity and reliability.

Stroke 5 mm

• Piston diameter 12 mm
• Piston rod thread M5
• Based on standard ISO 21287
• Cushioning Elastic cushioning rings/plates at both ends
• Mounting position optional
• Mode of operation Double-acting
• Piston-rod end Male thread
• Position detection Via proximity switch
• Symbol 00991217
• Variants Piston rod at one end
• Operating pressure 0.1 MPa ... 1 MPa
• Operating pressure 1 bar ... 10 bar
• Operating pressure 14.5 psi ... 145 psi
• Operating medium Compressed air to ISO 8573-1:2010 [7:4:4]
• Note on operating and pilot medium Lubricated operation possible (in which case lubricated operation will always be required)
• Corrosion resistance class CRC 2 - Moderate corrosion stress
• LABS (PWIS) conformity VDMA24364-B1/B2-L
• Cleanroom class Class 6 according to ISO 14644-1
• Ambient temperature -20  deg C ... 80deg C
• Impact energy in end positions 0.07 J
• Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke 51 N
• Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke 68 N
• Moving mass 13 g
• Product weight 70 g
• Type of mounting Either: With through-hole Via female thread With accessories
• Pneumatic connection M5
• Note on materials RoHS-compliant
• Material collar screws Steel
• Material cover Anodised wrought aluminium alloy
• Material seals TPE-U(PUR)
• Material piston rod High-alloy steel
• Material cylinder barrel Smooth-anodised wrought aluminium alloy
